GS5310 Portable Time Stamp Recorder

The GS5310 portable GPS event recorder is designed primarily for GNSS signal reception and time synchronization, enabling high-precision internal time keeping.

It captures external trigger signals in real time and stamps them with accurate timestamps upon locking. Simultaneously, it outputs multiple signals that can serve as trigger sources for other equipment.

The device also features a network interface, allowing remote operations such as system reset and timestamp data download.

Application areas





Applications requiring high-precision time recording;

Field combat test range;

Simulated training test range.

• It can receive GNSS satellite navigation signals as external clock source to perform time and frequency calibration for the device;

  When using satellite navigation signals, you can manually select single GPS, single BD2, or combined (GN) working together;

• It supports normally-open, normally-closed, and 28V signal trigger modes, and can also serve as a TTL trigger recorder;

• It features two trigger recording modes: single trigger mode and continuous trigger mode. ① Single trigger mode: All states remain unchanged before reset, and the device is in a ready-to-trigger state after reset. ② Continuous trigger mode: The trigger interval is adjustable from 1 to 20 seconds, and the device can be automatically triggered after the device's timer expires;

• Features programmable timing outputs, including four TTL signals, four normally-open outputs, and four normally-closed outputs. Each channel has independently preset timing and adjustable delay output capability;

• It has a lock time display function ( i.e., trigger time ): hour (2 digits), minute (2 digits), second (2 digits), millisecond (3 digits), microsecond (3 digits);

• It features LED indicators for "Power", "Reset", "Trigger" and other statuses (high-brightness red LEDs are used as indicator lights), as well as status output function;

• It has time synchronization signal output function: 1 channel 10MHz sine wave, 1 channel 1PPS signal;

• Dual AC/DC power capability. DC power uses an external battery with a runtime of no less than 8 hours;

• It has remote control capabilities and can achieve functions such as remote reset, time-related settings, and lock time display via UDP and

• TCP network protocols;

• The equipment packaging box contains a built-in battery and battery charging/discharging management functions, and is designed to withstand vibration and other environmental conditions.
